Product Overview
The Fluke 1AC II
is a compact, easy-to-use non-contact voltage detector. Touch the tester's tip
to a terminal, outlet, or cord to check for voltage. When voltage is present,
the tip glows red and the tester beeps.
Ideal for
identifying energized circuits, verifying power presence, and detecting wiring
issues in homes, commercial spaces, and industrial environments.
Specifications
Operating Principle
Senses
the steady electrostatic field produced by AC voltage through insulation
without requiring direct conductor contact. A red glow and audible tone (when
enabled) indicate voltage presence.
Voltage
Sensing Range
90
V AC to 1000 V AC (nominal)
Detector
Tip
Flat-tip
design
Light
Source
High-intensity
red LED
Safety
and Compliance
IEC
61010-1: Pollution Degree 2
IEC
61010-2-030: CAT IV 1000 V
EMC:
IEC 61326-1 Portable
IP40
ingress protection
Environmental
Conditions
Operating
Temperature: -10°C to 50°C
Operating
Humidity:
0%–95%
(0°C–30°C)
0%–75%
(30°C–40°C)
0%–45%
(40°C–55°C)
Operating Altitude: up to 3000 m
