- Stock: In Stock
- Model: True RMS Clamp Meter
Product overview:
Fluke 323 True RMS Clamp Meter
Fluke 323 True-RMS
clamp meter delivers rugged reliable performance for general electrical
troubleshooting
The Fluke 323 clamp meter is a good basic troubleshooting
tool for commercial and residential electricians. It includes True RMS
measurements, optimized ergonomics, and large display for efficient
troubleshooting. It's designed to perform in the toughest environments and
provide noise-free, reliable results, so you can trust it to help you
confidently diagnose problems almost anywhere. Use it to verify the presence of
load current, AC voltage, and continuity of circuits, switches, fuses and
contacts. Its slim, compact size and rugged design make it well suited for
measuring current up to 400 A in tight cable compartments.
Specifications: Fluke 323 True RMS Clamp
Meter
Specifications | ||
AC current | Range | 400.0 A |
Accuracy | 2% ± 5 digits (45 Hz to 65 Hz) | |
DC current | Range | - |
Accuracy | - | |
AC voltage | Range | 600.0 V |
Accuracy | 1.5% ± 5 digits | |
DC voltage | Range | 600.0 V |
Accuracy | 1.0% ± 5 digits | |
Resistance | Range | 400.0 Ω/ 4000 Ω |
Accuracy | 1.0% ± 5 digits | |
Continuity | ≤ 70 Ω | |
Capacitance | - | |
Frequency | - | |
AC response | True-RMS | |
Backlight | - | |
Data hold | Yes | |
Contact temperature | - | |
Min/Max | - | |
Size | H x W x D (mm) | 207 x 75 x 34 |
Max wire diameter | 30 mm (600 MCM) | |
Weight | 265 g | |
Category rating | CAT III 600 V | |
