- Stock: In Stock
- Model: UT125C UNI-T
UT125C Pocket Size
Digital Multimeter 600V
UT125C is a pocket size, ergonomic and reliable multimeter
with 4000 display counts. It is a useful tool for electronics Dyers working
with low currents (< 0.4A). This product is CE/cETLus certified and complies
with CAT III 600V.
Features
1. Small size, easy to carry and operate
2. 600V DC/AC voltage measurement
3. 400mA DC/AC current measurement
4. Resistance/Capacitance/Diode/Continuity test
5. Frequency/Duty cycle measurement
6. CE (EMC, LVD, RoHS), cETLus
7. CAT III 600V
8. 1m drop test
Specifications | Range | UT125C |
DC voltage (V) | 600V | ±(0.5%+5) |
AC voltage (V) | 600V | ±(1.2%+5) |
DC current (A) | 400mA | ±(1.8%+5) |
AC current (A) | 400mA | ±(2%+8) |
Resistance (Ω) | 40MΩ | ±(1%+5) |
Capacitance (F) | 100μF | ±(4%+10) |
Frequency (Hz) | 10Hz~60kHz | ±(0.1%+5) |
Duty cycle | 20%~80% | Reference |
Features | ||
NCV | | √ |
Diode test/Continuity test | | √ |
Low battery indication | | √ |
Data hold/Auto power off | | √ |
Operating temperature | 0℃~50℃ | |
General Characteristics | ||
Power | 1.5V battery (R03) x 2 | |
Display | 38mm x 23mm | |
Product color | Red and grey | |
Product net weight | 180g | |
Product size | 112mm x 58mm x 35mm | |
Standard accessories | Batteries | |
Standard individual packing | Gift box, English manual | |
